Steerable 50 Tons Customized Concrete Products Trackless Transport Trolley
For The Trackless Transfer Cart, It’s Easy To Turn 360 Degrees At A Minimum Turning Radius. The Operation Ways Are Hand Held Push Button And Remote Control, The Steering Wheel Sets Coordinate With Die Wheel Sets To Carry The Loads On The Customized Platform. This Series Flat Cart's Power Source Is DC Motor Power, Through Reducer Enlarge The Torque And Provide Power To Die Wheel Sets.
The Safety Device Is LED Audible And Visual Alarm As Warning Symbol, And The External Automatic Charger Is Equipped For Battery Recharge. Battery Is Easy To Replace Within 5min , Full Load Continuous Running 6 Hours , The Intelligent Charging Device Can Charge The Battery Full Within 8 Hours. Therefore, It Was Widely Used In Machinery Factories, Warehouses And Metallurgical Plants As A Workshop Transport Or With The Crane Transport Heavy Loads Over Cross.
Advantages Of Trackless Transfer Cart On Ground
-
Can Turn 360 Degree
-
No Strict Requires On Rails
-
Can Be Applied High Using Frequency Condition
-
Can Be Used In High-Temperature Environment
-
Can Be Used In Explosion-Proof Environment
| Technical parameters for trackless electric transfer carts |
| rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 |
| impacted rated load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 |
| structure of frame | steel plates welded, beam structure |
| max. wheel load(t) | 2.8 | 4.3 | 4.8 | 5.6 | 7.7 | 10 | 12 |
| ground requirement | cement floor | steel plate ground |
| table size(mm) | 3000×2000 | 3600×2000 | 4000×2200 | 4500×2200 | 5000×2200 | 5500×2300 | 6000×2300 |
| height of the whole cart(mm) | 450 | 530 | 600 | 600 | 650 | 700 | 700 |
| ground clearance(mm) | 50 |
| wheels base(mm) | 1500 | 1700 | 1800 |
| axles distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 |
| turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 |
| turning type | turning while driving with no stop |
| control method for turning | control button |
| turning structure | mechanical |
| motor power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 |
| wheel diameter(mm) | 300 x 4 | 350 x 4 | 400 x 4 | 400 x 6 | 500 x 6 |
| wheel material | ZG55+hydropur ture |
| running speed(m/min) | 0-20 |
| brake principle | electric magnetic brake |
| operation method | with wire or no wire |
| battery maintenance | free of maintenance |
| charger's installation | installed on cart | split-type |
| radar control | 3-0.3m, automatic stop for obstacles |
| warning equipment | sound and light |
| other functions | turning light, night light and power display |
Functional Description Of Mould Plant Battery Powered Trackless Trolley
The BWP Series DC Motor Industrial Handling Equipment Material Carbon Steel Rail Platform Transfer Carts With Casters. Usually, Accumulator, Mains Powered And Generator Are Choose As Power Source. The Current Is Supplied And Generator Are Choose As Power Source.
The Electric Trackless Transfer Flat Car Is Supplied To Pulling Motor Through Electric Control System, Which Makes The Electric Trackless Transfer Car For Metal Industry Apply Heavy Load Rail Transfer Cart Start, Stop, Move Background, Turn Around And Realize Other Functions.
Also, We Will Provide Intelligent Automatic Rapid Charger With The Car. Positioning Fixture, Lift Platform And Other Assistive Device Are Optional To Meet Different Demands On Various Occasions.
The PLC Is Also Alternative If The DC Motor Industrial Handling Equipment Material Carbon Steel Rail Platform Transfer Carts With Casters Is Necessary.
